Specification
Universal 4 GSM Band for Global;
Wide Range Working Voltage: 9-75V DC;
GPS Locate, GPRS Upload Location to Server;
Built in Shock Sensor for Car Move and Shock Alarm;
Remote Turn Off Car Engine (need add optional cut relay);
Built in rechargeable battery for power down alarm (Tracker removed alarm).
Before Using
1.Power ON / OFF
When power is OFF, connect the tracker power line to vehicle battery, the tracker will power on automatically.
When power is OFF, please press the “ON-OFF” button beside the tracer case, till the RED LED is ON or FLASH, release the button and the tracker is power ON.
When power is ON, please press the “ON-OFF” button beside the tracer case, till the RED LED is OFF, release the button and the tracker is power OFF.
When the battery voltage in the tracker is too low, the tracker will power off automatically.
2.Install SIM card
Unfasten the screw in the back case of the tracker, and open the case of the tracker , the SIM card holder will be seen, pull the metal cover to “OPEN” direction, and the cover can be opened up, and put the SIM card in the holder (Metal pin face to down), close the metal cover and push the metal cover to “LOCK” direction, after a sound of lock the SIM card has been locked and installed.
4.If you have many vehicles , we can create a user that can see all your trackers after you login, this can be used as fleet management, ask your dealer to contact us to get your administrator user name and password of your fleet.
Setting by SMS
1. All of the following commands must be lowercase letters, all of the send commands will be reply. If set successful it will reply "set successfully!” otherwise need to set again. Send the corresponding commands the device will reply the corresponding results.
1.1 Binding owner mobile number:
If you want to use SMS to set device’s working parameter or control the device, you must bind your mobile number first. Device only accept SMS commands of the owner mobile number.In order to ensure the safety of users, you must use the password. The initial password is “123456”. Password can be modified.
The owner mobile number bind command:admin123456#00000000000
Example: admin123456#13800138000
If the owner mobile number is bind successful, the device will reply: admin ok
Note: you can only set one owner mobile number.if you need the change the owner’s mobile number,you need to bind again by sending the command.
1.2 Modify password
The initial password is 123456
Command: password123456#888888
If the password is modified successful, the device will reply: "change password ok,your new password is 888888”
1.3Inquire the parameter setting
Command: check
Reply Message: Terminal ID:01234567890, IP:121.37.43.82, PORT:9881,
interval upload:30,sleep:20,alarm:0,VibSensor:3,VibTime:1
Terminal ID:11020127332 -- Serial Number
IP:121.37.43.82, PORT:9881 -- Server IP and port
upload:30 -- GPRS Data upload interval, default is 30S
the service platform; and send alarm message and latitude and longitude to the center number by SMS and call the owner number. If owner mobile number does not answer, the device will call several times.
Command: fortify1
Reply Message:”fortify ok”or”acc on,can not fortify”
Command:fortify0
Reply Message:”no fortify ok”
2.2 Alarm clear
When alarm was triggered, the device will call the owner mobile number, if you answer it, the device will not call again,on the contrary,the device will call 6 times continuously, if you want to clear it, you can send “fortify0” command to the device.
Reply Message: "no fortify ok"
2.3 Cut off vehicle’s oil or power(option)
When the vehicle was stolen, you can cut off the vehicle’s oil or power by SMS.
Command: “cut off”
means: cut off the vehicle’s oil or power
Reply message:”cut off ok”
Command:”recover”
means: recover the vehicle’s oil or power
Reply message:”recover ok”
Attention: Turning off engine is very dangerous when car is driving, this will make the car difficult to control and maybe cause a accident, so we recommend make the relay cut the start motor wire, this will make you can not remote turn off car engine, but you can make the car engine can not be started.
Location check
1. Get location of vehicle by SMS from server
Command: where
This function needs server support. If server not support, please ignore it.
If GPS fixed, the device replies address.
If GPS not fixed, the device replies: "unable to get the correct GPS data, please trY
